TP-Link extender setup support presents How to configure RE550 Wifi Range Extender via Web GUI (new-designed blue UI) to extend an existing wireless network’s coverage?

However, to improve the user experience, in the recent and new-coming Range Extender products we have used a new designed Web GUI. It’s more friendly and helpful for users and now let’s introduce how to configure the Range Extender with a new designed UI via Web GUI.

Before we configure RE550, please check the hardware connection first:

Plug your RE550 into a power outlet near your wireless router or AP.
Use an Ethernet cable to connect your RE550 to your PC.

Note: We strongly suggest you should configure your RE550 via wired connection. But if you don’t have any PC, or the RE product you use like TL-WA854RE doesn’t have any Ethernet port, you can only configure RE550/TL-WA854RE via Wi-Fi in this situation.

Now let’s begin configuring RE550:

1. Log into the Web GUI of RE550 using its domain name: tplinkrepeater.net or default IP: 192.168.0.254.

The default username and password are both “admin”. Click “Login” to log into the Web GUI of RE550.

Note: If it’s the first time that you configure your RE550, after clicking “Login”, you can see the pop-up window below:

It’s recommended to set a new username and password. But if you don’t need, please click the “x” in the top-right corner to quit the pop-up window.

2. Select your Region here, and click “Next”.

3. Then RE550 will start to scan all 2.4G & 5G wireless networks around. After scanning, click the wireless network you want to extend and type the wireless password.

Here I connect to “C3200_2.4G”, click “Next” to continue to configure 5G wireless settings.

4. Click to select the 5G wireless network you want to extend, then type the wireless password. Here I connect to “C3200_5G”, click “Next” to continue.

Note: If your router is only a single band wireless router (2.4GHz), you needn’t configure it here and just click “Skip” in the bottom-right corner.

5. After configuring 2.4G & 5G wireless network, here we can choose whether to change the SSID of Extended 2.4G & 5G Wi-Fi. As we can see from below, RE550 will use the same SSID as the main router by default. Click “Next” to continue.

Note:- By default, RE550 will use the same SSID as the main router (C3200). In this way you can set up a roaming network: your wireless clients can switch to the wireless network with the better signal strength either from your main Router/AP or your RE550. However, the roaming experience will be decided by your wireless clients. For more detailed information about “roaming”, please refer to: What can I do if my client can’t roam between my wireless router and TP-Link AP & Range Extender product?
Of course you can also set a different SSID in your RE550. In this way you can’t experience “roaming network” but you can manually choose to connect to either Wi-Fi from your main Router/AP or RE550 according to the signal strength your wireless clients get.

6. Here is a Summary of your configuration, click “Finish” to finish the configuration if all is fine.

7. After the Reboot, RE550 will connect to C3200 automatically. If there is a “√” in Internet icon, it means RE550 has connected to the Internet and you can enjoy the extended wireless network by RE550.

Note:- You can also determine whether RE550 has connected to the main router/Internet according to its LED lights:

If 2.4G or 5G LED is on, it means RE550 has connected to the 2.4GHz or 5GHz wireless network of your host network.
